JD5225C Casambi Bluetooth 75W 6.3A 220-240VAC

Standalone design applicable to LED strips, light bars, linear lights, light films, magnetic track lights and decorative lights
Dimmable color-tunable constant voltage driver with full power output, high power factor, high efficiency and long service life
Bluetooth communication developed on Casambi platform with strong networking capacity
Smooth high-performance dimming, flicker-free and silent operation
Dimming range: 1%~100%, built-in soft start function
Compatible with Casambi App control
Output short-circuit, open-circuit and overload protection
Conforms to extra-low voltage safety standards
Screw-locking terminals for input and output wiring
Ambient temperature range: -20℃~+45℃, maximum case temperature: 90℃
Suitable for Class I, II and III luminaires
Protection Class II

Consult Now Buy Now

Model Number

JD5225C
Rated Voltage

220-240Vac
Output Current

6.3A
Product Dimension

265*42*30mm
Dimming Mode

Casambi Bluetooth
Dimming Range

1-100%
Protection

Output short-circuit, open-circuit and overload protection
Protection Grade

IP20
Frequency

50-60Hz
Weight

Net weight: 255.2±10g per piece, small package: 284.5g per piece, medium carton: 4.57kg per carton, large carton: 19.17kg per carton
Packaging

Medium carton: 15pcs per carton Large carton: 60pcs per carton
Output Channel

3CCT
IP Rating

IP20
Working Mode

Constant Voltage
Output Power

Max.75W
Output Voltage

12V
PF

>0.95
Operating Temperature

-20～+45℃
Storage Temperature

-20~85°C/10~95%RH
Maximum Case Temperature

90℃
Withstand Voltage

Input to Output:3750Vac,5mA,60s
Insulation Resistance

Input to Output:100MQ/500VDC/25°C/70%RH
Safety Standards

EN61347-1:2015,EN61347-2-13:2014+A1：2017
Service Life

>50000h@tc=90℃
SELV

SELV 60V
Installation Method

Standalone
Warranty

5 years
