JD6220 PLC 12W 150-500mA 100-240VAC DIP

Independent design, suitable for LED strip, LED bar, linear light, light film, magnetic track light, decorative light
Dimmable color‑tunable CV driver, high efficiency and long service life
Bluetooth communication, developed based on MiJia platform, strong networking capability
Smooth high‑performance dimming, flicker‑free, noise‑free
Dimming range 1…100%, built‑in soft‑start function
Integrated with MiJia App, supports Xiaoai voice control, supports Xiaomi HyperConnect
Output short‑circuit, open‑circuit and overload protection
Complies with SELV standard
Screw‑lock input and output terminals
Ambient temperature: -20～+45℃, maximum enclosure temperature 75℃
Suitable for Class Ⅰ Ⅱ Ⅲ luminaires
Protection Class Ⅱ

Consult Now Buy Now

Model Number

JD6220
Rated Voltage

220-240Vac
Output Current

350-700mA
Product Dimension

120*38*23mm
Dimming Mode

PLC
Dimming Range

1-100%
Protection

Output short‑circuit, open‑circuit and overload protection
Protection Grade

IP20
Frequency

50-60Hz
Weight

Net Weight:94.3±10g/pcs,Small Pack:106g/pcs,Inner Pack:6.65kg/carton,Outer Pack:27.5kg/carton
Packaging

Inner Pack:40pcs/carton,Outer Pack:160pcs/carton
Output Channel

3CCT
IP Rating

IP20
Working Mode

CC
Output Power

Max.20W
Output Voltage

15-40V
PF

>0.9
Operating Temperature

-20～+45℃
Storage Temperature

-20~85°C/10~95%RH
Maximum Case Temperature

75℃
Withstand Voltage

Input to Output:3750Vac,5mA,60s
Insulation Resistance

Input to Output:100MQ/500VDC/25°C/70%RH
Safety Standards

EN61347-1:2015,EN61347-2-13:2014+A1：2017
Service Life

>50000h@ta<45℃
SELV

SELV 60V
Installation Method

Independent
Warranty

5 years
