2.4G RF Independent CC Series

HomeProduct2.4G RF

2.4G RF Independent CC Series

Series Features

Compact design, suitable for small cutout downlights & spotlights and linear lights.
Dimmable CC driver, 100-240V~ input, high power factor, high efficiency, long lifespan.
2.4G RF wireless communication, Mesh networking capability, strong anti-interference.
Smooth high-performance dimming, flicker-free, noise-free.
Dimming range 0.5...100%, with built-in soft start function.
Supports local remote control and panel control, remote control distance (open area) >30m.
Output current selectable via DIP switch.
Output short circuit, open circuit and overload protection.
Complies with SELV (Safety Extra Low Voltage) standard.
Input and output screw terminal blocks.
Ambient temperature -20 to +45°C, maximum enclosure temperature 75/80/90°C.
Suitable for Class I, II and III luminaires.
Protection Class II.

Consult Now Buy Now

Model

Output Power

Rated Voltage

Output Voltage

Output Current

PF

Size
JD9134 2.4G RF 11.9W 350-700mA 100-240VAC DIP

Max.11.9W

100-240Vac

2-17V

350-700mA

>0.9

126*30*20mm
JD9119 2.4G RF12W 150-500mA 100-240VAC DIP

Max.12W

220-240Vac

9-40V

150-500mA

>0.9

126*30*20mm
JD9120 2.4G RF 20W 350-700mA 100-240VAC DIP

Max.20W

220-240Vac

9-40V

350-700mA

>0.9

120*38*23mm
JD9124 2.4G RF 30W 550-900mA 100-240VAC DIP

Max.30W

100-240Vac

9-40V

550-900mA

>0.9

165*42*30mm
JD9121 2.4G RF 40W 700-1050mA 100-240VAC DIP

Max.40W

100-240Vac

9-40V

700-1050mA

>0.9

165*42*30mm

Dimming Mode

2.4G RF
Dimming Range

0.5-100%
Protection

Output short circuit, open circuit and overload protection.
Protection Class

IP20
Frequency

50-60Hz
Weight

Net Weight: 67.9±10g/pcs, Small Pack: 79.4g/pcs, Middle Carton: 6.65kg/carton, Master Carton: 27.5kg/carton (See specification sheet for details)
Package

Middle Carton: 80/48/30 pcs/carton, Master Carton: 320/192/120 pcs/carton
Operating Temperature

-20～+45℃
Storage Temperature

-20~85°C/10~95%RH
Max Case Temperature

75℃/80℃/90℃
Withstand Voltage

Input to Output:3750Vac,5mA,60s
Insulation Resistance

Input to Output:100MQ/500VDC/25°C/70%RH
Safety Standard

EN61347-1:2015,EN61347-2-13:2014+A1：2017
Lifetime

>50000h@ta<45℃
