Matter Independent CV Series

Independent design, suitable for LED strips, LED ribbons, linear lights, light films, magnetic track lights and decorative lights
Dimmable CV driver, full power, high efficiency, long service life
Wi-Fi/Thread communication, developed based on Matter with strong networking capability
Smooth high-performance dimming, flicker-free, noise-free
Dimming range 1…100%, built-in soft start function
Supports Tmall Genie, Baidu Duer, Xiaomi Xiao Ai, Zhixiao Manager, Tencent Xiaowei, Tencent Dingdang and JD Dingdong control
Output short-circuit, open-circuit and overload protection
Compliant with SELV standard
Screw-locked terminals for input and output wiring
Ambient temperature -20～+45℃, maximum case temperature 90℃
Suitable for Class I, II and III luminaires
Protection Class II

Consult Now Buy Now

Dimming Mode

Matter
Dimming Range

1-100%
Protection

Output short-circuit, open-circuit and overload protection
Protection Class

IP20
Frequency

50-60Hz
Weight

Net Weight: 153.1±10g/pcs, Small Pack: 169.9g/pcs, Inner Pack: 5.39kg/carton, Outer Pack: 22.49kg/carton (See datasheet for details)
Package

Inner Pack: 30pcs/15pcs per carton, Outer Pack: 120pcs/60pcs per carton
Operating Temperature

-20～+45℃
Storage Temperature

-20~85°C/10~95%RH
Max Case Temperature

90℃
Withstand Voltage

Input to Output:3750Vac,5mA,60s
Insulation Resistance

Input to Output:100MQ/500VDC/25°C/70%RH
Safety Standard

EN61347-1:2015,EN61347-2-13:2014+A1：2017
Lifetime

>50000h@tc=90℃
