Zigbee Independent CC Series

Compact design, suitable for small cutout downlights & spotlights and linear lights.
Dimmable CC driver, 100-240V~ input, high power factor, high efficiency, long lifespan.
Zigbee communication, developed based on Tuya platform, strong networking capability.
Smooth high-performance dimming, flicker-free, noise-free.
Dimming range 1...100%, with built-in soft start function.
Supports control via Tmall Genie, Xiaodu, Xiaoai, Xiaozhi Guanjia, Tencent Xiaowei, Tencent Dingdang, JD Dingdong, etc.
Output current selectable via DIP switch.
Output short circuit, open circuit and overload protection.
Complies with SELV (Safety Extra Low Voltage) standard.
Input and output screw terminal blocks.
Ambient temperature -20 to +45°C, maximum enclosure temperature 75/80/90°C.
Suitable for Class I, II and III luminaires.
Protection Class II.

Consult Now Buy Now

Dimming Mode

ZigBee
Dimming Range

1-100%
Protection

IP20
Protection Class

IP20
Frequency

50-60Hz
Weight

Net Weight: 67±10g/pcs, Small Pack: 78.2g/pcs, Middle Carton: 6.56kg/carton, Master Carton: 27.1kg/carton (See specification sheet for details)
Package

Inner Pack: 80pcs/48pcs/30pcs per carton, Outer Pack: 432pcs/192pcs/120pcs per carton
Operating Temperature

-20～+45℃
Storage Temperature

-20~85°C/10~95%RH
Max Case Temperature

75/80/90℃
Withstand Voltage

Input to Output:3750Vac,5mA,60s
Insulation Resistance

Input to Output:100MQ/500VDC/25°C/70%RH
Safety Standard

EN61347-1:2015,EN61347-2-13:2014+A1：2017
Lifetime

>50000h@ta<45℃
